Inverters

The X3-ULTRA is a versatile 3ph hybrid inverter that includes inversion, solar charging, and battery charging. The X3 ULTRA series can be used with different capacities of SolaX battery. The X3 Ultra can also store surplus energy in batteries for later use. It is important to understand that this is a hybrid solar PV inverter and battery storage controller. This means it needs to be sized just like a regular inverter would be and, if it is being retrofitted, will replace the existing inverter. For G100 Applications, please contact SolaX to perform a software update remotely when the product is installed. Additionally, the SolaX CHINT three phase CT energy meter is recommended. AC attributes Max power: 30000W Max current: 39.9A Number of phases: 3 DC attributes Number of MPPT 3 V range of MPPT 160-950V Max power 60kW Max voltage 1000V Start up voltage 200V System Max efficiency 98% IP rating IP66 Weight 47kg Dimensions 696 x 529 x 240 mm CommunicationWarranty 5 years Key features Max. 36A DC input per MPPT 3 MPPT, 6 Strings 100% Unbalanced Output AI-Driven Energy Management

Read more less

The X3-FIT G4 15kW is a 3-phase AC coupled inverter designed by SolaX. Once your load supply is satisfied by the power generated from your solar panels, the intelligent SolaX X3 Retro Fit will direct excess energy into your battery, ready for later use. Additionally this AC coupled inverter can act as a backup power supply should your home experience a loss of power. The X3 Retro Fit will then send the stored power back to the home, ensuring you are never left in the dark even during a power-cut. VPP Function EPS Switchover Time <10ms with up to 150% output for 60s Max. 110% nominal apparent AC power Flexible Peak Shaving Compatible with WiFi V2.0 Optional three-phase unbalanced output For G100 Applications, please contact SolaX to perform a software update remotely when the product is installed. Additionally, the Solax CHINT three phase CT energy meter is recommended. AC attributes Max power: 15000W Max current: 24.1A Number of phases: 3 System Max efficiency 98% IP rating IP65 Weight 30kg Dimensions(H*W*D)  503*503*199mm

Read more less

The SolarEdge three phase inverter combines sophisticated digital control technology with efficient power conversion architecture to achieve superior solar power harvesting and best-in-class reliability. The fixed-voltage technology ensures the solar inverter is always working at its optimal input voltage regardless of the number of modules in a string or environmental conditions. A proprietary data monitoring receiver has been integrated into the inverter and aggregates the power optimizer performance data from each PV module. This data can be transmitted to the web and accessed via the SolarEdge monitoring platform for performance analysis fault detection and troubleshooting of PV systems.   ManufacturerSolarEdge Technologies Phases3 Phase Power Rating kW33.3 Inverter TypeOptimised Inverter Built in DCYes No. of MPPTN/A Built in CommunicationOptional Commodity Code85044086 Dimensions (mm) (H x W x D)550 x 317 x 273

Read more less

Solax X3 MEGA G2 50kW 3ph solar inverter, which delivers up to 98.4% efficiency and a maximum input voltage of 1100V as well as outstanding energy performance with its wide MPPT voltage range, enhancing power yield. The Solax X3 Mega G2 is IP66 rated, and equipped with safety and security features such as Arc-fault circuit                                                 interrupter and SPD protection.  AC attributes Max rated power: 50kW Max rated current: 72.5A Number of phases: 3 DC attributes Max power 75kW Max Isc currentMPPT range 46A180-1000V Max voltage 1100V Start up voltage 200V System Max efficiency 98.4% IP rating IP66 Weight 44.5kg Dimensions 630 x 521 x 286mm Key features IP66 ProtectionAFCI ProtectionOver current and temperature protectionOver/under voltage protectionBuilt-in export power control

Read more less

SolaX have developed the 125kW X3-Forth as a commercial and roof-top scale string inverter with quality, reliability and efficiency and an IP66 protection rating. The X3-Forth features 12 MPPTs, each boasting an ultra-wide 180-1000V voltage range, a maximum Isc current of 46A and 150% PV oversizing, optimising a systems energy harvesting capabilities.  AC attributes Max power: 125kW Max current: 200A Number of phases: 3 DC attributes Max power 188kW Max Isc currentMPPT range 46180-1000V Max voltage 1000 Start up voltage 200V System Max efficiency 98.6% IP rating IP66 Weight 87kg Dimensions 985 x 660 x 327.5mm Key features 12 MPPTs with high input currentIP66 ProtectionAFCI Protection24 hours operation monitoringAC and DC Surge Protection

Read more less

Part No: PYL-F-H3-BATT-BMU-20.5 Storage Systems - Li-ion Battery Pack Weight: 188.2 kg Battery Type: Lithium Ion Nominal Energy: 20480 Wh Depth of discharge: 95.00 % Voltage: 409 V Continuous Discharge Rate (Normal Use): 20480 W Maximum Discharge Rate (5 Minutes): 20480 W Surge Discharge Rate (15 Seconds): 22528 W Maximum Charge Rate (5 Minutes): 20480 W

Read more less

Part No: PYL-F-H3-BATT-BMU-15.4 Storage Systems - Li-ion Battery Pack Weight: 146.2 kg Battery Type: Lithium Ion Nominal Energy: 15360 Wh Depth of discharge: 95.00 % Voltage: 307 V Continuous Discharge Rate (Normal Use): 15360 W Maximum Discharge Rate (5 Minutes): 15360 W Surge Discharge Rate (15 Seconds): 16896 W Maximum Charge Rate (5 Minutes): 15360 W

Read more less

Part No: PYL-F-H3-BATT-BMU-10.2 Storage Systems - Li-ion Battery Pack Weight: 104.2 kg Battery Type: Lithium Ion Nominal Energy: 10200 Wh Depth of discharge: 95.00 % Voltage: 204 V Continuous Discharge Rate (Normal Use): 10200 W Maximum Discharge Rate (5 Minutes): 10200 W Surge Discharge Rate (15 Seconds): 10608 W Maximum Charge Rate (5 Minutes): 10200 W

Read more less

Part No: PYL-F-H3-BATT Storage Systems - Li-ion Battery Pack Proven lithium iron phosphate storage technology (LiFePO4) 5.12 kWh per battery module - Flexibly configurable from 10.24 to 35.8 kWh per tower (2 to 7 battery modules) Up to 6 battery towers can be connected in parallel - Total capacity of up to 215 kWh Up to 864 V system voltage 1C rating enables faster charging and discharging Globally certified Designed for 8000+ charging cycles or 15 years 24/7 monitoring via app Versatile use with the most common inverter manufacturers (see compatibility list) Warranty: 10 year standard Supplier Part No: FH10050 Module Weight: 42 kg Battery Type: Lithium Ion Nominal Energy: 5100 Wh Depth of discharge: 90.00 % Voltage: 102 V Continuous Discharge Rate (Normal Use): 4080 W Maximum Discharge Rate (5 Minutes): 5100 W Surge Discharge Rate (15 Seconds): 5100 W Maximum Charge Rate (5 Minutes): 5100 W

Read more less

Part No: PYL-F-H3-BATT-BMU-35.8 Storage Systems - Li-ion Battery Pack This part is made up of the following items: 7 x PYL-F-H3-BATT Pylontech Force H3 5.1kWh High Voltage Battery Module   1 x PYL-F-H3-BMU-BASE Pylontech Force H3 BMU with base and cables   Not suitable for Solis Hybrid as the battery voltage is higher than 600 V   Weight: 314.2 kg Battery Type: Lithium Ion Nominal Energy: 35840 Wh Depth of discharge: 95.00 % Voltage: 716 V Continuous Discharge Rate (Normal Use): 35840 W Maximum Discharge Rate (5 Minutes): 35840 W Surge Discharge Rate (15 Seconds): 39424 W Maximum Charge Rate (5 Minutes): 35840 W

Read more less

Part No: PYL-F-H3-BATT-BMU-30.7 Storage Systems - Li-ion Battery Pack This part is made up of the following items: 6 x PYL-F-H3-BATT Pylontech Force H3 5.1kWh High Voltage Battery Module   1 x PYL-F-H3-BMU-BASE Pylontech Force H3 BMU with base and cables   Not suitable for Solis Hybrid as the battery voltage is higher than 600 V   Weight: 272.2 kg Battery Type: Lithium Ion Nominal Energy: 30720 Wh Depth of discharge: 95.00 % Voltage: 614 V Continuous Discharge Rate (Normal Use): 30720 W Maximum Discharge Rate (5 Minutes): 30720 W Surge Discharge Rate (15 Seconds): 33792 W Maximum Charge Rate (5 Minutes): 30720 W

Read more less

Part No: SOL-8.0-S6-DT-DC Inverters - Main Units Rating: 8,000W Phases: 1 S6-GR1P8K2 Max. efficiency 97.7% String current up to 18A/32A Wide voltage range and low startup voltage 2 MPPT design with precise MPPT algorithm Integrated Export Power Manager (EPM) AFCI protection, proactively reduces fire risk Compact and lightweight Friendly and adaptable connection to the grid     Supplier Part No: S6-GR1P8K2 Weight: 12.5 kg Rated Power: 8,000 W Min PPT Voltage: 90 V Max PPT Voltage: 520 V DC Startup Voltage: 120 V DC Shutdown Voltage: 90 V Max Input Voltage: 600 V Max DC Power: 10,400 W Max AC Power (5 Minutes): 8,000 W Surge AC Power (1 Second): 8,000 W Max DC Current: 37.5 A Max DC Inputs: 3 Has DC Fuses: 0 Connector: MC4   Included Connectors: 4 Euro Efficiency: 97.3 % Transformer: None MPPT Quantity : 2 Has Integrated DC Switch: Yes Warranty: 5 years

Read more less

Part No: SE-20000-APP Inverters - Main Units Rating: 20,000W Solar Edge 20000 3phase BASIC inverter with Set APP function (no display)   THIS INVERTER HAS NO TRACKERS AND REQUIRES POWER OPTIMISERS TO FUNCTION. The SolarEdge inverters combine a sophisticated, digital control technology and single stage, efficient power conversion architecture to achieve superior solar power harvesting and best-in-class reliability. The fixed-voltage technology ensures the solar inverter is always working at its optimal input voltage, regardless of the number of modules in a string or environmental conditions.   Supplier Part No: SE20K-RW00IBNM4 Weight: 45 kg Rated Power: 20,000 W

Read more less

Part No: SOL-S5-GC60K-DC Inverters - Main Units Rating: 60,000W Phases: 3 S5-GC60K - Series 5 Three Phase Grid-Tied Inverter Product Features Max. efficiency of 98.7%  Type-II over-voltage surge protection for both DC and AC Wide voltage range - Ultra low start-up voltage of 195V and max PV input voltage of 1100V Max PV DC Power of 90kW 32A input per MPPT, 16A input for each PV string Maximum output power of 66kW  6 MPPT design with precise MPPT algorithm, with 2 DC inputs per MPPT effectively reducing string mismatch Intelligent monitoring, Smart I-V Curve Diagnosis Integrated AFCI (DC arc-fault circuit protection) IP66 Rated and C5 Anti-Corrosion Level Integrated DC switch for emergency shut-down of PV power or safe PV maintenance DC reverse-polarity protection Supports PLC/GPRS/WiFi communication with less wiring and reduced installation costs 5-year standard warranty Register on SolisCloud, to support remote upgrade and control.   Supplier Part No: S5-GC60K Weight: 56 kg Rated Power: 60,000 W Min PPT Voltage: 195 V Max PPT Voltage: 1,000 V DC Startup Voltage: 195 V DC Shutdown Voltage: 180 V Max Input Voltage: 1,100 V Max DC Power: 90,000 W Max AC Power (5 Minutes): 66,000 W Surge AC Power (1 Second): 66,000 W Max DC Current: 192 A Max DC Inputs: 12 Has DC Fuses: 0 Connector: MC4   Included Connectors: 24 Euro Efficiency: 98.4 % Transformer: None MPPT Quantity : 6 Has Integrated DC Switch: Yes Warranty: 5 years

Read more less

Part No: SOL-100K-5G-PRO-DC Inverters - Main Units Rating: 100,000W Phases: 3 Solis 5G Pro 100kW 3PH Inverter 8 MPPTs, max. efficiency 98.5% 150% DC/AC ratio Compatible with bifacial modules IP66 AFCI protection, proactively reduces fire risk Globally recognised branded componentry for longer life Night SVG function  Intelligent string monitoring, smart I-V curve scan Remote firmware upgrade with simple operation Power line communication (PLC) (optional) DC side supports "Y" connector Supports aluminium wire access to reduce cost Notes: Pro 5G Solis 100kW come with integrated DC isolators but not the AC option -  AC Isolator is required   Supplier Part No: Solis-100K-5G-PRO Weight: 93 kg Rated Power: 100,000 W Min PPT Voltage: 160 V Max PPT Voltage: 1,000 V DC Startup Voltage: 180 V DC Shutdown Voltage: 160 V Max Input Voltage: 1,100 V Max DC Power: 100,000 W Max AC Power (5 Minutes): 100,000 W Surge AC Power (1 Second): 110,000 W Max DC Current: 272 A Max DC Inputs: 16 Has DC Fuses: 0 Connector: MC4   Included Connectors: 32 Euro Efficiency: 98 % Transformer: None MPPT Quantity : 8 Has Integrated DC Switch: Yes Warranty: 5 years

Read more less

The EcoFlow PowerOcean redefines home energy storage with an advanced safety system, LFP battery tech, a fire prevention module, and an IP65-certified design. The EcoFlow PowerOcean comes with a 15-year warranty, with batteries expandable up to 45kWh while offering over 6,000 charge cycles. The EcoFlow PowerOcean is a secure, scalable, and future-proof power investment for your home. Main features: 15 year industry leading warranty Instant cell-level Anti-Fire protection Built in heating pads to ensure optimum performance even in sub-zero temperatures. UK technical support IP65 certification, ensuring it stands strong against dust ingress and resistant to low-pressure water jets from any direction. 95% D.O.D Expandable up to 45kWh per inverter Expandable up to 2 inverters in parallel  Individual BMS allowing optimal performance and ensures compatibility with newer model batteries Industry-leading APP API to charge from Octopus tariffs such as Agile & Flux Sleek, slim design    At the heart of EcoFlow PowerOcean lies our advanced LFP battery pack, meticulously engineered for peak performance and unparalleled safety. This battery pack blends high-efficiency output with innovative safety features, delivering relentless power and peace of mind to all PowerOcean users.

Read more less

S5-GC(25-36)K-LV three phase series string inverter adopt 4 MPPT design to provide a more flexible configuration scheme with a smaller environmental impact rate and higher generation efficiency   ManufacturerSolis Weight54.5 kg Phases3 Phase Power Rating kW30 Inverter TypeString Inverter Built in DCYes No. of MPPT2 Built in CommunicationOptional Commodity Code85044086 Dimensions (mm) (H x W x D)691 x 578 x 338

Read more less

Solis S6 30kW 3 Phase Hybrid Inverter with DC - 4 MPPT for HV Batteries (WIFI/LAN), High voltage, three-phase energy storage for commercial applications. The inverter series, which boasts a maximum charge/discharge current of 70A+70A across two independently controlled battery ports, has four integrated MPPTs with a string current capacity of up to 20A – ensuring unmatched power delivery. Whether for on or off-grid applications, the S6-EH3P(30-50)K-H series supports parallel operation of up to six units, with a backup port capable of supporting 1.6 times overload for short durations. This latest range compatible with an array of batteries, thanks to its wide voltage range, and offers peak shaving control in both "self-use" and "generator" modes.   ApplicationCommercial ManufacturerSolis Weight73.0 kg Inverter TypeHybrid Inverter No. of MPPT4 Commodity Code85044086 Dimensions (mm) (H x W x D)530 x 880 x 290

Read more less

Safety and Power Independence in Every Charge This Product is The Ecoflow PowerOcean DC Fit Converter The EcoFlow PowerOcean redefines home energy storage with an advanced safety system, LFP battery tech, active fire protection module, and an IP65-certified design. Expandable up to 15kWh, it offers over 6000 charge cycles and a 15-year warranty— a secure, scalable, and future-proof power investment for your home. The EcoFlow 5kW DC Converter is a crucial part of the PowerOcean DC Fit Retrofit Battery Storage solution. This unique PV-coupled retrofit battery solution is extremely easy to set up and smoothly integrates into an existing solar system on the PV side. The system eliminates the need to add a new storage inverter or replace an existing solar inverter. TECHNICAL SPECIFICATION Max. input charging power: 5kW (2.5kW per string) Max. input charging current: 12A per string Max. input voltage (absolute maximum): 1000V d.c. Operating voltage range: 150-800V d.c. Supported solar inverter type: Single phase / Three phase Bypass power: 15kW per string Max. output current: 20A per string Max. output voltage: 1000V d.c. Max. output discharging power: 5kW (2.5kW per string) IP rating: IP65 Flow meter included. Data Sheet Brochure User Manual Installation Guide Compatibility Notice

Read more less

Click Here To Register For The On-line Installation Training Course INCLUDED IN PACKAGE:   7.6KW HYBRID INVERTER 3.3 KWH BATTERIES X 6 TOP COVER FLOOR BASE WIFI DONGLE SMART METER INTERNAL DC BREAKER HYBRID INVERTER 7.6KW Max DC input 10kwp 7600W nominal AC output power IP67 rating Dimensions (W x H x D)mm 600  x 1866 x 243 10  year warranty BATTERIES 19.9kW OF POWER FROM THE 6 x BATTERIES COMBINED DOC 100% VOLTAGE RANGE 30v - 43.8v WEIGHT OF EACH BATTERY: 35kg IP RATING: IP67 INTEGRATED PROTECTION Battery Input Reverse / Polarity Protection Over load Protection (DC-AC side) AC Short Circuit Current Protection / Output Short Protection Output Over Current Protection DC (PV+Battery) Short Circuit Current Protection AC Surge Protection (SPD -Type) Output Over Voltage Protection Grid and Back-up (SPD Type II) Anti Islanding Protection PV String Input Reverse Polarity Protection Ground Fault Monitoring Temperature Protection (Inverter + Battery) Integrated DC Switch (PV - Disconnector) Emergency Stop WARRANTY Inverter: 10 YearsBattery:   >80% Capacity 10 Years / 6000 cyclesAccessories: 2 Years

Read more less

Click Here To Register For The On-line Installation Training Course INCLUDED IN PACKAGE: 7.6KW HYBRID INVERTER 3.3 KWH BATTERIES X 5 TOP COVER FLOOR BASE WIFI DONGLE SMART METER INTERNAL DC BREAKER HYBRID INVERTER 7.6KW Max DC input 10kwp 7600W nominal AC output power IP67 rating Dimensions (W x H x D)mm 600  x 1651 x 243 10  year warranty BATTERIES 16.6kW OF POWER FROM THE 5 x BATTERIES COMBINED DOC 100% VOLTAGE RANGE 30v - 43.8v WEIGHT OF EACH BATTERY: 35kg IP RATING: IP67 INTEGRATED PROTECTION Battery Input Reverse / Polarity Protection Over load Protection (DC-AC side) AC Short Circuit Current Protection / Output Short Protection Output Over Current Protection DC (PV+Battery) Short Circuit Current Protection AC Surge Protection (SPD -Type) Output Over Voltage Protection Grid and Back-up (SPD Type II) Anti Islanding Protection PV String Input Reverse Polarity Protection Ground Fault Monitoring Temperature Protection (Inverter + Battery) Integrated DC Switch (PV - Disconnector) Emergency Stop WARRANTY Inverter: 10 YearsBattery:   >80% Capacity 10 Years / 6000 cyclesAccessories: 2 Years

Read more less

Click Here To Register For The On-line Installation Training Course INCLUDED IN PACKAGE: 7.6KW HYBRID INVERTER 3.3 KWH BATTERIES X 2 TOP COVER FLOOR BASE WIFI DONGLE SMART METER INTERNAL DC BREAKER HYBRID INVERTER 7.6KW Max DC input 10kwp 7600W nominal AC output power IP67 rating Dimensions (W x H x D)mm 600  x 1006 x 243 10  year warranty BATTERIES 6.6kW OF POWER FROM THE 2 x BATTERIES COMBINED DOC 100% VOLTAGE RANGE 30v - 43.8v WEIGHT OF EACH BATTERY: 35kg IP RATING: IP67 INTEGRATED PROTECTION Battery Input Reverse / Polarity Protection Over load Protection (DC-AC side) AC Short Circuit Current Protection / Output Short Protection Output Over Current Protection DC (PV+Battery) Short Circuit Current Protection AC Surge Protection (SPD -Type) Output Over Voltage Protection Grid and Back-up (SPD Type II) Anti Islanding Protection PV String Input Reverse Polarity Protection Ground Fault Monitoring Temperature Protection (Inverter + Battery) Integrated DC Switch (PV - Disconnector) Emergency Stop WARRANTY Inverter: 10 YearsBattery:   >80% Capacity 10 Years / 6000 cyclesAccessories: 2 Years

Read more less

Part No: FE-R-100.0 Inverters - Main Units Rating: 100,000W FOX ESS - Grid-Tied Inverter - R Series - 100.0kW R100 The R Series inverter range is aimed at 3-phase commercial installations, with inverter options from 75kW to 110kW. PV String Current Monitoring Arc Fault Circuit Interrupter Function PID Recovery LED, Wi-Fi + APP IP66 and C5 Protection 13A / 16A Input Current, Compatible with Bifacial Module Don't forget: You must register your install with Fox online to activate the 10 year product warranty, otherwise it's 5 years as standard. Please click here for registration page. Please check the warranty document for more information.   Supplier Part No: R100 Weight: 90 kg Rated Power: 100,000 W

Read more less

Part No: FE-H3-6.0-CT Storage Systems - Hybrid Inverter This part is a special offer made up of the following items: Part   1 x FE-H3-6.0 FOX ESS H3 6.0KW 3PH Hybrid/AC Inverter   1 x FE-3PH-METER-CT Fox CT Meter (compatible with AC, HY & AIO ranges)   Includes FE-3PH-METER-CT Harness the power of the sun day and night with FoxESS' groundbreaking line of hybrid inverters. Easy installation - Plug & Play, built-in fuse protection. Maximum yields - Low starting voltage, 97.3% maximum efficiency Maximum flexibility - 3 battery types to choose from, True 3-phase backup power Monitoring - Monitor remotely via app or web portal. FoxESS inverters are configurable with the following batteries: 1x FE-HV-BMS + (4-8)x FE-HV-2600 1x ECM-2900 (master) + 2-5x ECS-2900 (slave) 1x ECM-4100 (Master) + 2-5x ECS-4100 (Slave) FoxESS inverters are not compatible with SolarEdge or Huawei optimizers, but with those from Tigo. 3PH Smart Meter included in packaging. Don't forget: You must register your install with Fox online to activate the 10 year product warranty, otherwise it's 5 years as standard. Please click here for registration page. Please check the warranty document for more information. PLEASE NOTE: This product requires the following meter for full operation: FE-3PH-METER-CT  Weight: 28 kg Rated Power: 6,000 W Min PPT Voltage: 160 V Max PPT Voltage: 1,000 V DC Startup Voltage: 160 V DC Shutdown Voltage: 160 V Max Input Voltage: 1,000 V Max DC Power: 9,000 W Max AC Power (5 Minutes): 6,000 W Surge AC Power (1 Second): 9,000 W Max DC Current: 14 A Max DC Inputs: 2 Has DC Fuses: 1 Connector: MC4   Included Connectors: 4 Euro Efficiency: 97.8 % Transformer: N/A MPPT Quantity : 2 Has Integrated DC Switch: Yes Warranty: 5 years

Read more less

Part No: FE-H3-PRO-30.0-CT Storage Systems - Hybrid Inverter This part is a special offer made up of the following items: Part   1 x FE-H3-PRO-30.0 Fox ESS H3 Pro 20kW 3PH Hybrid Inverter   1 x FE-3PH-METER-CT Fox CT Meter (compatible with AC, HY & AIO ranges)   Includes FE-3PH-METER-CT Harness the power of the sun day and night with FoxESS' ground breaking line of hybrid inverters. Easy installation - Flexible configuration, Plug & Play, built-in fuse protection. High Voltage - Includes high-voltage batteries for maximum round-trip efficiency. IP65 Rated - Engineered to last with maximum flexibility. Suitable for outdoor installation. Remote Monitoring - Monitor remotely via app or web portal. Parallelable up to 10 inverters with FE-H3-PRO-EMS (Available mid-late May). Easily expand your system by adding extra batteries. There are three battery series you can choose from, which enables a storage capacity of up to 86.40 kWh.  Fox Inverters are compatible with the following batteries: 1x FE-HV-BMS + (3-16)x FE-HV-2600 1x ECM-2900 (Master) + (2-6)x ECS-2900 (Slave) (Connector Type A) 1x ECM-2900 (Master) + (2-6)x ECS-2900 (Slave) (Connector Type B) 1x ECM-4100 (Master) + (2-6)x ECS-4100 (Slave) 1x ECM-4300 (Master) + (2-6)x ECS-4300 (Slave) 1x ECM-4800 (Master) + (2-6)x ECS-4800 (Slave) This Inverter can have a MAXIMUM of 2 stacks with 7 modules per stack (1x Master + 6x Slaves), for a TOTAL of 2x Master + 12x Slaves.      PLEASE NOTE: This product requires the following meter for full operation: FE-3PH-METER-CT  Don't forget: You must register your install with Fox online to activate the 10 year product warranty, otherwise it's 5 years as standard. Please click here for registration page. Please check the warranty document for more information. G99 and G100 Certified   Weight: 57.5 kg Rated Power: 30,000 W Min PPT Voltage: 160 V Max PPT Voltage: 1,000 V DC Startup Voltage: 160 V DC Shutdown Voltage: 160 V Max Input Voltage: 1,000 V Max DC Power: 45,000 W Max AC Power (5 Minutes): 30,000 W Surge AC Power (1 Second): 33,000 W Max DC Current: 96 A Max DC Inputs: 6 Has DC Fuses: 0 Connector: MC4   Included Connectors: 12 Euro Efficiency: 97.4 % Transformer: None MPPT Quantity : 3 Has Integrated DC Switch: Yes Warranty: 5 years

Read more less

Part No: FE-H3-PRO-25.0-CT Storage Systems - Hybrid Inverter This part is a special offer made up of the following items: Part   1 x FE-H3-PRO-25.0 Fox ESS H3 Pro 20kW 3PH Hybrid Inverter   1 x FE-3PH-METER-CT Fox CT Meter (compatible with AC, HY & AIO ranges)   Includes FE-3PH-METER-CT Harness the power of the sun day and night with FoxESS' ground breaking line of hybrid inverters. Easy installation - Flexible configuration, Plug & Play, built-in fuse protection. High Voltage - Includes high-voltage batteries for maximum round-trip efficiency. IP65 Rated - Engineered to last with maximum flexibility. Suitable for outdoor installation. Remote Monitoring - Monitor remotely via app or web portal. Parallelable up to 10 inverters with FE-H3-PRO-EMS (Available mid-late May). Easily expand your system by adding extra batteries. There are three battery series you can choose from, which enables a storage capacity of up to 86.40 kWh.  Fox Inverters are compatible with the following batteries: 1x FE-HV-BMS + (3-16)x FE-HV-2600 1x ECM-2900 (Master) + (2-6)x ECS-2900 (Slave) (Connector Type A) 1x ECM-2900 (Master) + (2-6)x ECS-2900 (Slave) (Connector Type B) 1x ECM-4100 (Master) + (2-6)x ECS-4100 (Slave) 1x ECM-4300 (Master) + (2-6)x ECS-4300 (Slave) 1x ECM-4800 (Master) + (2-6)x ECS-4800 (Slave) This Inverter can have a MAXIMUM of 2 stacks with 7 modules per stack (1x Master + 6x Slaves), for a TOTAL of 2x Master + 12x Slaves.      PLEASE NOTE: This product requires the following meter for full operation: FE-3PH-METER-CT  Don't forget: You must register your install with Fox online to activate the 10 year product warranty, otherwise it's 5 years as standard. Please click here for registration page. Please check the warranty document for more information. G99 and G100 Certified   Weight: 57.5 kg Rated Power: 25,000 W Min PPT Voltage: 160 V Max PPT Voltage: 1,000 V DC Startup Voltage: 160 V DC Shutdown Voltage: 1,000 V Max Input Voltage: 1,000 V Max DC Power: 37,500 W Max AC Power (5 Minutes): 25,000 W Surge AC Power (1 Second): 27,500 W Max DC Current: 96 A Max DC Inputs: 6 Has DC Fuses: 1 Connector: MC4   Included Connectors: 12 Euro Efficiency: 97.4 % Transformer: N/A MPPT Quantity : 3 Has Integrated DC Switch: Yes Warranty: 5 years

Read more less

Part No: FE-H3-PRO-20.0-CT Storage Systems - Hybrid Inverter This part is a special offer made up of the following items: Part   1 x FE-H3-PRO-20.0 Fox ESS H3 Pro 20kW 3PH Hybrid Inverter   1 x FE-3PH-METER-CT Fox CT Meter (compatible with AC, HY & AIO ranges)   Includes FE-3PH-METER-CT Harness the power of the sun day and night with FoxESS' ground breaking line of hybrid inverters. Easy installation - Flexible configuration, Plug & Play, built-in fuse protection. High Voltage - Includes high-voltage batteries for maximum round-trip efficiency. IP65 Rated - Engineered to last with maximum flexibility. Suitable for outdoor installation. Remote Monitoring - Monitor remotely via app or web portal. Parallelable up to 10 inverters with FE-H3-PRO-EMS (Available mid-late May). Easily expand your system by adding extra batteries. There are three battery series you can choose from, which enables a storage capacity of up to 86.40 kWh.  Fox Inverters are compatible with the following batteries: 1x FE-HV-BMS + (3-16)x FE-HV-2600 1x ECM-2900 (Master) + (2-6)x ECS-2900 (Slave) (Connector Type A) 1x ECM-2900 (Master) + (2-6)x ECS-2900 (Slave) (Connector Type B) 1x ECM-4100 (Master) + (2-6)x ECS-4100 (Slave) 1x ECM-4300 (Master) + (2-6)x ECS-4300 (Slave) 1x ECM-4800 (Master) + (2-6)x ECS-4800 (Slave) This Inverter can have a MAXIMUM of 2 stacks with 7 modules per stack (1x Master + 6x Slaves), for a TOTAL of 2x Master + 12x Slaves.      PLEASE NOTE: This product requires the following meter for full operation: FE-3PH-METER-CT  Don't forget: You must register your install with Fox online to activate the 10 year product warranty, otherwise it's 5 years as standard. Please click here for registration page. Please check the warranty document for more information. G99 and G100 Certified   Weight: 52.5 kg Rated Power: 20,000 W Min PPT Voltage: 160 V Max PPT Voltage: 1,000 V DC Startup Voltage: 160 V DC Shutdown Voltage: 1,000 V Max Input Voltage: 1,000 V Max DC Power: 30,000 W Max AC Power (5 Minutes): 20,000 W Surge AC Power (1 Second): 22,000 W Max DC Current: 96 A Max DC Inputs: 6 Has DC Fuses: 1 Connector: MC4   Included Connectors: 12 Euro Efficiency: 97.4 % Transformer: N/A MPPT Quantity : 3 Has Integrated DC Switch: Yes Warranty: 5 years

Read more less

Part No: FE-H3-12.0-CT Storage Systems - Hybrid Inverter This part is a special offer made up of the following items: Part   1 x FE-H3-12.0 FOX ESS H3 10.0KW 3PH Hybrid Inverter   1 x FE-3PH-METER-CT Fox CT Meter (compatible with AC, HY & AIO ranges)   Includes FE-3PH-METER-CT Harness the power of the sun day and night with FoxESS' groundbreaking line of hybrid inverters. Easy installation - Plug & Play, built-in fuse protection. Maximum yields - Low starting voltage, 97.3% maximum efficiency Maximum flexibility - 3 battery types to choose from, True 3-phase backup power Monitoring - Monitor remotely via app or web portal. FoxESS inverters are configurable with the following batteries: FoxESS inverters are configurable with the following batteries: 1x FE-HV-BMS + (4-8)x FE-HV-2600 1x ECM-2900 (Master) + 2-6x ECS-2900 (Slave) 1x ECM-4100 (Master) + 2-6x ECS-4100 (Slave) 1x ECM-4300 (Master) + 2-6x ECS-4300 (Slave) 1x ECM-4800 (Master) + 2-6x ECS-4800 (Slave) FoxESS inverters are not compatible with SolarEdge or Huawei optimizers, but with those from Tigo. 3PH Smart Meter included in packaging. Don't forget: You must register your install with Fox online to activate the 10 year product warranty, otherwise it's 5 years as standard. Please click here for registration page. Please check the warranty document for more information. PLEASE NOTE: This product requires the following meter for full operation: FE-3PH-METER-CT  Weight: 28 kg Rated Power: 12,000 W Min PPT Voltage: 160 V Max PPT Voltage: 950 V DC Startup Voltage: 160 V DC Shutdown Voltage: 160 V Max Input Voltage: 1,000 V Max DC Power: 15,000 W Max AC Power (5 Minutes):  12,000 W Surge AC Power (1 Second): 13,200 W Max DC Current: 26 A Max DC Inputs: 3 Has DC Fuses: 0 Connector: MC4   Included Connectors: 4 Euro Efficiency: 98 % Transformer: N/A MPPT Quantity : 2 Has Integrated DC Switch: Yes Warranty: 5 years

Read more less

Part No: FE-H3-8.0-CT Storage Systems - Hybrid Inverter This part is a special offer made up of the following items: Part   1 x FE-H3-8.0 FOX ESS H3 8.0KW 3PH Hybrid Inverter   1 x FE-3PH-METER-CT Fox CT Meter (compatible with AC, HY & AIO ranges)   Includes FE-3PH-METER-CT Harness the power of the sun day and night with Fox ESS' ground breaking line of hybrid inverters. Easy installation - Plug & Play, built-in fuse protection. Maximum yields - Low starting voltage, 97.3% maximum efficiency Maximum flexibility - 3 battery types to choose from, True 3-phase backup power Monitoring - Monitor remotely via app or web portal. FoxESS inverters are configurable with the following batteries: FoxESS inverters are configurable with the following batteries: 1x FE-HV-BMS + (4-8)x FE-HV-2600 1x ECM-2900 (Master) + 2-6x ECS-2900 (Slave) 1x ECM-4100 (Master) + 2-6x ECS-4100 (Slave) 1x ECM-4300 (Master) + 2-6x ECS-4300 (Slave) 1x ECM-4800 (Master) + 2-6x ECS-4800 (Slave) FoxESS inverters are not compatible with SolarEdge or Huawei optimizers, but with those from Tigo. 3PH Smart Meter included in packaging. Don't forget: You must register your install with Fox online to activate the 10 year product warranty, otherwise it's 5 years as standard. Please click here for registration page. Please check the warranty document for more information. PLEASE NOTE: This product requires the following meter for full operation: FE-3PH-METER-CT  Weight: 28 kg Rated Power: 8,000 W Min PPT Voltage: 160 V Max PPT Voltage: 1,000 V DC Startup Voltage: 160 V DC Shutdown Voltage: 160 V Max Input Voltage: 1,000 V Max DC Power: 10,400 W Max AC Power (5 Minutes): 8,000 W Surge AC Power (1 Second): 8,800 W Max DC Current: 26 A Max DC Inputs: 3 Has DC Fuses: 1 Connector: MC4   Included Connectors: 4 Euro Efficiency: 98 % Transformer: N/A MPPT Quantity : 2 Has Integrated DC Switch: Yes Warranty: 5 years

Read more less

Part No: FE-H3-6.0 Storage Systems - Hybrid Inverter Harness the power of the sun day and night with FoxESS' groundbreaking line of hybrid inverters. Easy installation - Plug & Play, built-in fuse protection. Maximum yields - Low starting voltage, 97.3% maximum efficiency Maximum flexibility - 3 battery types to choose from, True 3-phase backup power Monitoring - Monitor remotely via app or web portal. FoxESS inverters are configurable with the following batteries: 1x FE-HV-BMS + (4-8)x FE-HV-2600 1x ECM-2900 (master) + 2-5x ECS-2900 (slave) 1x ECM-4100 (Master) + 2-5x ECS-4100 (Slave) FoxESS inverters are not compatible with SolarEdge or Huawei optimizers, but with those from Tigo. 3PH Smart Meter included in packaging. Don't forget: You must register your install with Fox online to activate the 10 year product warranty, otherwise it's 5 years as standard. Please click here for registration page. Please check the warranty document for more information. PLEASE NOTE: This product requires the following meter for full operation: FE-3PH-METER-CT  Supplier Part No: FE-H3-6.0 Weight: 28 kg Rated Power: 6,000 W Min PPT Voltage: 160 V Max PPT Voltage: 1,000 V DC Startup Voltage: 160 V DC Shutdown Voltage: 160 V Max Input Voltage: 1,000 V Max DC Power: 9,000 W Max AC Power (5 Minutes): 6,000 W Surge AC Power (1 Second): 9,000 W Max DC Current: 14 A Max DC Inputs: 2 Has DC Fuses: 1 Connector: MC4   Included Connectors: 4 Euro Efficiency: 97.8 % Transformer: N/A MPPT Quantity : 2 Has Integrated DC Switch: Yes Warranty: 5 years

Read more less

Part No: SUN2000-115KTL-M2 Inverters - Main Units Rating: 115,000W Phases: 3 SUN2000-115KTL-M2 This three-phase string inverter is ideal for grid-tied systems of large-scale PV plants and commercial distributed grid-tied systems. Typically, a grid-tied PV system consists of the PV string, solar inverter, AC combiner box, and transformer station.   Supplier Part No: 01074694-008 Weight: 93 kg Rated Power: 115,000 W Min PPT Voltage: 200 V Max PPT Voltage: 1,000 V DC Startup Voltage: 200 V DC Shutdown Voltage: 0 V Max Input Voltage: 1,100 V Max DC Power: 125,000 W Max AC Power (5 Minutes): 115,000 W Surge AC Power (1 Second): 125,000 W Max DC Current: 20 A Max DC Inputs: 20 Has DC Fuses: 0 Connector: MC4   Included Connectors: 2 Euro Efficiency: 98.4 % Transformer: None MPPT Quantity : 10 Has Integrated DC Switch: Yes

Read more less

The home battery It’s sturdy, it’s super great value,and it’s safe as houses. System Overview Inverter Data Sheet Battery Data Sheet Inverter Installation Guide Battery Installation Guide SEE THE FULL INSTALLATION GUIDE ON YOU TUBE  INCLUDED IN PACKAGE: 6KW HYBRID INVERTER 5.2KWH BATTERY X 5 WIFI DONGLE WITH 1 YEAR PORTAL ACCESS GEM120 METER INVERTER TO BATTERY CABLE BATTERY FOOT 160A BATTERY BREAKER BATTERY TO BATTERY CABLE X 4 PARALLEL BATTERY FEET X 4 THE DIGITS HYBRID INVERTER 3.6KW 5400W max. DC power 3600W nominal AC output power IP20 rating Dimensions 20W x 195D x 475H (mm) 3 year warranty, extendable to 5 THE FEATURES 6kW of power from a single battery Over-charging and over-discharging protection Over-current protection Over and under temperature protection Short-circuit protection Clever battery reverse protection function Able to run up to 5 batteries in parallel – for a capacity of over 25kWh Seriously good cell technology – using prismatic LiFePO4 cells Balancing comes built-in to the battery management system (BMS) Fine to run as a battery-only system for charging from a cheap, split rate electricity tariff THE DIGITS HOME BATTERY 5.2KWH 92% depth of discharge Design life of 10+ years IP20 rating Dimensions: 505D x 134W 440H (mm) 3 year warranty, extendable to 5

Read more less

The home battery It’s sturdy, it’s super great value,and it’s safe as houses. 5 Year warranty as standard, for all systems commissioned in May, June, and July 2024   System Overview Inverter Data Sheet Battery Data Sheet Inverter Installation Guide Battery Installation Guide SEE THE FULL INSTALLATION GUIDE ON YOU TUBE INCLUDED IN PACKAGE: 3.6KW HYBRID INVERTER 5.2KWH BATTERY X 5 WIFI DONGLE WITH 1 YEAR PORTAL ACCESS GEM120 METER INVERTER TO BATTERY CABLE BATTERY FOOT 160A BATTERY BREAKER BATTERY TO BATTERY CABLE X 4 PARALLEL BATTERY FEET X 4 THE DIGITS HYBRID INVERTER 3.6KW 5400W max. DC power 3600W nominal AC output power IP20 rating Dimensions 20W x 195D x 475H (mm) 5 Year warranty THE FEATURES 6kW of power from a single battery Over-charging and over-discharging protection Over-current protection Over and under temperature protection Short-circuit protection Clever battery reverse protection function Able to run up to 5 batteries in parallel – for a capacity of over 25kWh Seriously good cell technology – using prismatic LiFePO4 cells Balancing comes built-in to the battery management system (BMS) Fine to run as a battery-only system for charging from a cheap, split rate electricity tariff THE DIGITS HOME BATTERY 5.2KWH 92% depth of discharge Design life of 10+ years IP20 rating Dimensions: 505D x 134W 440H (mm) 3 year warranty, extendable to 5

Read more less

The home battery It’s sturdy, it’s super great value,and it’s safe as houses. System Overview Inverter Data Sheet Battery Data Sheet Inverter Installation Guide Battery Installation Guide SEE THE FULL INSTALLATION GUIDE ON YOU TUBE  INCLUDED IN PACKAGE: 6KW HYBRID INVERTER 5.2KWH BATTERY X 4 WIFI DONGLE WITH 1 YEAR PORTAL ACCESS GEM120 METER INVERTER TO BATTERY CABLE BATTERY FOOT 160A BATTERY BREAKER BATTERY TO BATTERY CABLE X 3 PARALLEL BATTERY FEET X 3 THE DIGITS HYBRID INVERTER 3.6KW 5400W max. DC power 3600W nominal AC output power IP20 rating Dimensions 20W x 195D x 475H (mm) 3 year warranty, extendable to 5 THE FEATURES 6kW of power from a single battery Over-charging and over-discharging protection Over-current protection Over and under temperature protection Short-circuit protection Clever battery reverse protection function Able to run up to 5 batteries in parallel – for a capacity of over 25kWh Seriously good cell technology – using prismatic LiFePO4 cells Balancing comes built-in to the battery management system (BMS) Fine to run as a battery-only system for charging from a cheap, split rate electricity tariff THE DIGITS HOME BATTERY 5.2KWH 92% depth of discharge Design life of 10+ years IP20 rating Dimensions: 505D x 134W 440H (mm) 3 year warranty, extendable to 5

Read more less

The home battery It’s sturdy, it’s super great value,and it’s safe as houses.   5 Year warranty as standard, for all systems commissioned in May, June, and July 2024   System Overview Inverter Data Sheet Battery Data Sheet Inverter Installation Guide Battery Installation Guide SEE THE FULL INSTALLATION GUIDE ON YOU TUBE INCLUDED IN PACKAGE: 3.6KW HYBRID INVERTER 5.2KWH BATTERY X 4 WIFI DONGLE WITH 1 YEAR PORTAL ACCESS GEM120 METER INVERTER TO BATTERY CABLE BATTERY FOOT 160A BATTERY BREAKER BATTERY TO BATTERY CABLE X 3 PARALLEL BATTERY FEET X 3 THE DIGITS HYBRID INVERTER 3.6KW 5400W max. DC power 3600W nominal AC output power IP20 rating Dimensions 20W x 195D x 475H (mm) 5 Year warranty THE FEATURES 6kW of power from a single battery Over-charging and over-discharging protection Over-current protection Over and under temperature protection Short-circuit protection Clever battery reverse protection function Able to run up to 5 batteries in parallel – for a capacity of over 25kWh Seriously good cell technology – using prismatic LiFePO4 cells Balancing comes built-in to the battery management system (BMS) Fine to run as a battery-only system for charging from a cheap, split rate electricity tariff THE DIGITS HOME BATTERY 5.2KWH 92% depth of discharge Design life of 10+ years IP20 rating Dimensions: 505D x 134W 440H (mm) 3 year warranty, extendable to 5

Read more less

The home battery It’s sturdy, it’s super great value,and it’s safe as houses.   5 Year warranty as standard, for all systems commissioned in May, June, and July 2024   System Overview Inverter Data Sheet Battery Data Sheet Inverter Installation Guide Battery Installation Guide SEE THE FULL INSTALLATION GUIDE ON YOU TUBE INCLUDED IN PACKAGE: 3.6KW HYBRID INVERTER 5.2KWH BATTERY X 3 WIFI DONGLE WITH 1 YEAR PORTAL ACCESS GEM120 METER INVERTER TO BATTERY CABLE BATTERY FOOT 160A BATTERY BREAKER BATTERY TO BATTERY CABLE X 2 PARALLEL BATTERY FEET X 2 THE DIGITS HYBRID INVERTER 3.6KW 5400W max. DC power 3600W nominal AC output power IP20 rating Dimensions 20W x 195D x 475H (mm) 5 Year warranty THE FEATURES 6kW of power from a single battery Over-charging and over-discharging protection Over-current protection Over and under temperature protection Short-circuit protection Clever battery reverse protection function Able to run up to 5 batteries in parallel – for a capacity of over 25kWh Seriously good cell technology – using prismatic LiFePO4 cells Balancing comes built-in to the battery management system (BMS) Fine to run as a battery-only system for charging from a cheap, split rate electricity tariff THE DIGITS HOME BATTERY 5.2KWH 92% depth of discharge Design life of 10+ years IP20 rating Dimensions: 505D x 134W 440H (mm) 3 year warranty, extendable to 5

Read more less

The home battery It’s sturdy, it’s super great value,and it’s safe as houses. System Overview Inverter Data Sheet Battery Data Sheet Inverter Installation Guide Battery Installation Guide SEE THE FULL INSTALLATION GUIDE ON YOU TUBE  INCLUDED IN PACKAGE: 6KW HYBRID INVERTER 5.2KWH BATTERY WIFI DONGLE WITH 1 YEAR PORTAL ACCESS GEM120 METER INVERTER TO BATTERY CABLE BATTERY FOOT 160A BATTERY BREAKER THE DIGITS HYBRID INVERTER 6.0KW 9000W max. DC power 6000W nominal AC output power IP20 rating Dimensions 20W x 195D x 475H (mm) 3 year warranty, extendable to 5 THE FEATURES 6kW of power from a single battery Over-charging and over-discharging protection Over-current protection Over and under temperature protection Short-circuit protection Clever battery reverse protection function Able to run up to 5 batteries in parallel – for a capacity of over 25kWh Seriously good cell technology – using prismatic LiFePO4 cells Balancing comes built-in to the battery management system (BMS) Fine to run as a battery-only system for charging from a cheap, split rate electricity tariff THE DIGITS HOME BATTERY 5.2KWH 92% depth of discharge Design life of 10+ years IP20 rating Dimensions: 505D x 134W 440H (mm) 3 year warranty, extendable to 5

Read more less

Features Safety and prevention of galvanic corrosion The Isolation Transformer eliminates any electrical continuity between AC shore power and the boat. It is essential for safety and eliminates the need for galvanic isolators and polarity alarms. Safety is taken for granted in case of a normal on-shore installation. A fuse will blow or a GFCI (Ground Fault Current Interrupter) will trip in case of a short circuit or current leakage to ground. Connecting the ground wire of the shore-side supply to the metal parts of the boat will result in galvanic corrosion (see below). Bringing only the live and neutral wire on board results in an unsafe situation because GFCIs will not work nor will a fuse blow in case of a short circuit to a metal part on the boat. Galvanic corrosion occurs when two dissimilar metals in electrical contact are simultaneously exposed to an electrically conducting fluid. Seawater and, to a lesser extent, fresh water are such fluids. In general, the more active alloy of the couple corrodes preferentially while the less active (more noble) material is cathodically protected. The rate of galvanic corrosion is a function of several variables including area ratios, conductivity of the fluid, temperature, nature of the materials, etc. It is a misunderstanding that galvanic corrosion occurs only in metal and aluminium hulls. In fact it can occur on any boat as soon as a metallic part (the shaft and propeller) is in contact with water. Galvanic corrosion will quickly dissolve your sacrificial anodes, and attack the shaft, propeller and other metal parts in contact with water as soon as the boat is connected to the shore-side supply. It might therefore be tempting not to connect the ground conductor: this is however extremely dangerous because GFCIs will not work nor will a fuse blow in case of a short circuit to a metal part on the boat. The best solution to avoid galvanic corrosion and at the same time prevent any unsafe situation is to install an Isolation Transformer to connect to the shore-side supply. The Isolation Transformer eliminates any electrical continuity between shore power and the boat. The shore power is fed to the primary side of the transformer and the ship is connected to the secondary. The Isolation Transformer completely isolates the boat from the shore ground. By connecting all metal parts to the neutral output on the secondary side of the transformer, a GFCI will trip or a fuse will blow in case of a short circuit. Soft start is a standard feature of a Victron Energy isolation transformer. It will prevent the shore power fuse from blowing due to the inrush current of the transformer, which would otherwise occur. It is also recommended, for optimal safety, to connect the secondary neutral of the transformer to ground when the boat is out of the water. Brand Victron Energy Manufacturer Part Number ITR040202041 Input 115 or 230 V Output 115 or 230 V Frequency 50/60 Hz Rating 17 / 8,5 A Soft Start Yes Transformer Type Toroidal (low noise, low weight) Input Circuit Breaker Yes Protection Category IP21 Dimensions H375 x W214 x D110mm Weight (kg) 10 Warranty 5 Years

Read more less

2 x  Huawei LUNA 5KWh battery module only   1 x  Huawei LUNA Power Module BMS   Smart String Energy By Luna  This is the complete 10KWh Luna Battery Product Features Flexible due to 5KWh that can be easy scaled from 5KWh to 30KWh 100% DOD pack level energy optimization Easy to install due to 12Kg power module and 50Kg battery module Lithium Iron Phosphate cells resulting is safe and reliable battery Auto Detected by battery Compatible with single and 3 Phase inverters Battery fault on module auto isolates to keep system safe battery module is 10 KWh per battery  this consists of 2 x battery modules and 1 x power module Nominal voltage of battery is 600VDC max output per module is 2500W 10 year warranty max is 2 x systems in parallel RS485 BMS communication  IP66 Data Sheet Huawei Luna

Read more less

The Pocket LAN V2.0 Dongle enables you to connect to your network via an ethernet cable, to connect to the SolaX cloud monitoring platform, allowing for a much more stable connection with less interference. This can prove a suitable solution for situations where WiFi can be difficult to connect to. Compatible with: X1-Smart X1-AC X1-FIT X3-FIT Key Features: Quick installation with 'Plug & Play' function IP65 protection rating Stable data transmission and good reliability Eco-green and modern design

Read more less

The X1-FIT G4 5.0kW W allows you to generate energy from your solar panels during the day and directs excess energy to the battery, ready for later use. In the event of a power cut the X1 FIT 'W' will use the stored power and act as an emergency power supply (EPS). For G100 Applications, please contact SolaX to perform a software update remotely when the product is installed. Additionally, the SolaX CHINT single phase CT energy meter is recommended. Key Features: VPP Function Remote Upgrade and Control Max. 110% nominal apparent AC power Flexible Peak Shaving Compatible with WiFi V2.0   AC attributes Max power: 5000W Max current: 40A Number of phases: 1 System Max efficiency 97% IP rating IP65 Weight 23kg Dimensions 482*417*181mm

Read more less

Part No: SE-100000-FUSE-FULL Inverters - Main Units Rating: 100,000W Phases: 3 This part is made up of the following items: 3 x SE-SYNERGY Synergy Secondary Unit without RapidShutdownDevice   1 x SE-100000-MNGR-F 100kW Synergy Manager FUSE DC Switch, MC4, DC SPD, 25A Fuses   Three Phase Synergy Inverter Main Features: Pre-commissioning feature for automated validation of system components and wiring during the site installation process and prior to grid connection. Easy 2-person installation with lightweight, modular design (each inverter consists of 2 or 3 Synergy Units and one Synergy Manager). Independent operation of each Synergy Unit enables higher uptime and easy serviceability. Built-in thermal sensors detect faulty wiring ensuring enhanced protection and safety. Built-in arc fault protection and optional rapid shutdown (depending on Synergy Manager used) Built-in PID mitigation for maximized system performance. Monitored and field-replaceable surge protection devices: integrated RS485 and Type 2 DC SPDs, optional Type 2 AC SPD. Integrated DC safety switch eliminates the need for external DC isolators. DC Fuses (Single Pole) 25A, optional required for more than 3 strings only  25Amp fuse is NOT compatible with the S1200 optimisers. 30Amp fuse (per phase) replacement is required for this inverter to work with the S1200 optimiser.    Please note FULL parts consist of 1x Synergy Manager and 2x Synergy Units ( 3x for 90 and 100kW) Weight: 114 kg Rated Power: 100,000 W Min PPT Voltage: 0 V Max PPT Voltage: 0 V DC Startup Voltage: 0 V DC Shutdown Voltage: 0 V Max Input Voltage: 0 V Max DC Power: 0 W Max AC Power (5 Minutes): 100,000 W Surge AC Power (1 Second): 0 W Max DC Current: 144.75 A Max DC Inputs: 0 Has DC Fuses: 12 Connector: MC4   Included Connectors: 12 Euro Efficiency: 98 % Transformer: None MPPT Quantity : 0 Has Integrated DC Switch: Yes Warranty: 12 years

Read more less

Part No: SE-90000-FUSE-FULL Inverters - Main Units Rating: 90,000W This part is made up of the following items: 3 x SE-SYNERGY Synergy Secondary Unit without RapidShutdownDevice   1 x SE-90000-MNGR-F 90kW Synergy Manager FUSE DC Switch, MC4, DC SPD, 25A Fuses   Three Phase Synergy Inverter Main Features: Pre-commissioning feature for automated validation of system components and wiring during the site installation process and prior to grid connection. Easy 2-person installation with lightweight, modular design (each inverter consists of 2 or 3 Synergy Units and one Synergy Manager). Independent operation of each Synergy Unit enables higher uptime and easy serviceability. Built-in thermal sensors detect faulty wiring ensuring enhanced protection and safety. Built-in arc fault protection and optional rapid shutdown (depending on Synergy Manager used) Built-in PID mitigation for maximized system performance. Monitored and field-replaceable surge protection devices: integrated RS485 and Type 2 DC SPDs, optional Type 2 AC SPD. Integrated DC safety switch eliminates the need for external DC isolators. DC Fuses (Single Pole) 25A, optional required for more than 3 strings only  25Amp fuse is NOT compatible with the S1200 optimisers. 30Amp fuse (per phase) replacement is required for this inverter to work with the S1200 optimiser.    Please note FULL parts consist of 1x Synergy Manager and 2x Synergy Units ( 3x for 90 and 100kW) Weight: 114 kg Rated Power: 90,000 W Min PPT Voltage: 0 V Max PPT Voltage: 0 V DC Startup Voltage: 0 V DC Shutdown Voltage: 0 V Max Input Voltage: 1,000 V Max DC Power: 0 W Max AC Power (5 Minutes): 82,800 W Surge AC Power (1 Second): 82,800 W Max DC Current: 0 A Max DC Inputs: 9 Has DC Fuses: 0 Connector: MC4   Included Connectors: 18 Euro Efficiency: 98 % Transformer: None MPPT Quantity : 0 Has Integrated DC Switch: Yes Warranty: 12 years

Read more less

Part No: SE-100000-SWITCH-FULL Inverters - Main Units Rating: 100,000W Phases: 3 This part is made up of the following items: 3 x SE-SYNERGY Synergy Secondary Unit without RapidShutdownDevice   1 x SE-100000-MNGR-S 100kW Synergy Manager SWITCH with DC Switch, MC4, DC SPD   Three Phase Synergy Inverter Main Features: Pre-commissioning feature for automated validation of system components and wiring during the site installation process and prior to grid connection. Easy 2-person installation with lightweight, modular design (each inverter consists of 2 or 3 Synergy Units and one Synergy Manager). Independent operation of each Synergy Unit enables higher uptime and easy serviceability. Built-in thermal sensors detect faulty wiring ensuring enhanced protection and safety. Built-in arc fault protection and optional rapid shutdown (depending on Synergy Manager used) Built-in PID mitigation for maximized system performance. Monitored and field-replaceable surge protection devices: integrated RS485 and Type 2 DC SPDs, optional Type 2 AC SPD. Integrated DC safety switch eliminates the need for external DC isolators. Please note FULL parts consist of 1x Synergy Manager and 2x Synergy Units ( 3x for 90 and 100kW) Weight: 114 kg Rated Power: 100,000 W Min PPT Voltage: 0 V Max PPT Voltage: 0 V DC Startup Voltage: 0 V DC Shutdown Voltage: 0 V Max Input Voltage: 1,000 V Max DC Power: 0 W Max AC Power (5 Minutes): 100,000 W Surge AC Power (1 Second): 0 W Max DC Current: 144.75 A Max DC Inputs: 0 Has DC Fuses: 12 Connector: MC4   Included Connectors: 12 Euro Efficiency: 98 % Transformer: None MPPT Quantity : 0 Has Integrated DC Switch: Yes Warranty: 12 years

Read more less

Part No: SE-90000-SWITCH-FULL Inverters - Main Units Rating: 90,000W This part is made up of the following items: 3 x SE-SYNERGY Synergy Secondary Unit without RapidShutdownDevice   1 x SE-90000-MNGR-S 90kW Synergy Manager SWITCH with DC Switch, MC4, DC SPD   Three Phase Synergy Inverter Main Features: Pre-commissioning feature for automated validation of system components and wiring during the site installation process and prior to grid connection. Easy 2-person installation with lightweight, modular design (each inverter consists of 2 or 3 Synergy Units and one Synergy Manager). Independent operation of each Synergy Unit enables higher uptime and easy serviceability. Built-in thermal sensors detect faulty wiring ensuring enhanced protection and safety. Built-in arc fault protection and optional rapid shutdown (depending on Synergy Manager used) Built-in PID mitigation for maximized system performance. Monitored and field-replaceable surge protection devices: integrated RS485 and Type 2 DC SPDs, optional Type 2 AC SPD. Integrated DC safety switch eliminates the need for external DC isolators. Please note FULL parts consist of 1x Synergy Manager and 2x Synergy Units ( 3x for 90 and 100kW) Weight: 114 kg Rated Power: 90,000 W Min PPT Voltage: 0 V Max PPT Voltage: 0 V DC Startup Voltage: 0 V DC Shutdown Voltage: 0 V Max Input Voltage: 1,000 V Max DC Power: 45,000 W Max AC Power (5 Minutes): 90,000 W Surge AC Power (1 Second): 90,000 W Max DC Current: 43.5 A Max DC Inputs: 9 Has DC Fuses: 0 Connector: MC4   Included Connectors: 18 Euro Efficiency: 98 % Transformer: None MPPT Quantity : 0 Has Integrated DC Switch: Yes Warranty: 12 years

Read more less

Part No: SE-100000-BASE-FULL Inverters - Main Units Rating: 100,000W Phases: 3 This part is made up of the following items: 3 x SE-SYNERGY Synergy Secondary Unit without RapidShutdownDevice   1 x SE-100000-MNGR-B 100kW Synergy Manager BASE No DC Switch, MC4, DC SPD   Three Phase Synergy Inverter Main Features: Pre-commissioning feature for automated validation of system components and wiring during the site installation process and prior to grid connection. Easy 2-person installation with lightweight, modular design (each inverter consists of 2 or 3 Synergy Units and one Synergy Manager). Independent operation of each Synergy Unit enables higher uptime and easy serviceability. Built-in thermal sensors detect faulty wiring ensuring enhanced protection and safety. Built-in arc fault protection and optional rapid shutdown (depending on Synergy Manager used) Built-in PID mitigation for maximized system performance. Monitored and field-replaceable surge protection devices: integrated RS485 and Type 2 DC SPDs, optional Type 2 AC SPD. Please note FULL parts consist of 1x Synergy Manager and 2x Synergy Units ( 3x for 90 and 100kW) Weight: 118 kg Rated Power: 100,000 W Min PPT Voltage: 0 V Max PPT Voltage: 0 V DC Startup Voltage: 0 V DC Shutdown Voltage: 0 V Max Input Voltage: 1,000 V Max DC Power: 150,000 W Max AC Power (5 Minutes): 100,000 W Surge AC Power (1 Second): 100,000 W Max DC Current: 144.75 A Max DC Inputs: 9 Has DC Fuses: 0 Connector: MC4   Included Connectors: 18 Euro Efficiency: 98 % Transformer: None MPPT Quantity : 0 Has Integrated DC Switch: Yes Warranty: 12 years

Read more less

Part No: SE-90000-BASE-FULL Inverters - Main Units Rating: 90,000W Phases: 3 This part is made up of the following items: 3 x SE-SYNERGY Synergy Secondary Unit without RapidShutdownDevice   1 x SE-90000-MNGR-B 90kW Synergy Manager BASE No DC Switch, MC4, DC SPD *   Three Phase Synergy Inverter Main Features: Pre-commissioning feature for automated validation of system components and wiring during the site installation process and prior to grid connection. Easy 2-person installation with lightweight, modular design (each inverter consists of 2 or 3 Synergy Units and one Synergy Manager). Independent operation of each Synergy Unit enables higher uptime and easy serviceability. Built-in thermal sensors detect faulty wiring ensuring enhanced protection and safety. Built-in arc fault protection and optional rapid shutdown (depending on Synergy Manager used) Built-in PID mitigation for maximized system performance. Monitored and field-replaceable surge protection devices: integrated RS485 and Type 2 DC SPDs, optional Type 2 AC SPD. Please note FULL parts consist of 1x Synergy Manager and 2x Synergy Units ( 3x for 90 and 100kW) Weight: 114 kg Rated Power: 90,000 W Min PPT Voltage: 0 V Max PPT Voltage: 0 V DC Startup Voltage: 0 V DC Shutdown Voltage: 0 V Max Input Voltage: 1,000 V Max DC Power: 135,000 W Max AC Power (5 Minutes): 90,000 W Surge AC Power (1 Second): 90,000 W Max DC Current: 0 A Max DC Inputs: 9 Has DC Fuses: 0 Connector: MC4   Included Connectors: 18 Euro Efficiency: 98 % Transformer: None MPPT Quantity : 0 Has Integrated DC Switch: Yes Warranty: 12 years

Read more less

Part No: SE-66600-FUSE-FULL Inverters - Main Units Rating: 66,600W Phases: 3 This part is made up of the following items: 2 x SE-SYNERGY Synergy Secondary Unit without RapidShutdownDevice   1 x SE-66600-MNGR-F 66.6kW Synergy Manager FUSE DC Switch, MC4, DC SPD, 25A Fuses   Three Phase Synergy Inverter Main Features: Pre-commissioning feature for automated validation of system components and wiring during the site installation process and prior to grid connection. Easy 2-person installation with lightweight, modular design (each inverter consists of 2 or 3 Synergy Units and one Synergy Manager). Independent operation of each Synergy Unit enables higher uptime and easy serviceability. Built-in thermal sensors detect faulty wiring ensuring enhanced protection and safety. Built-in arc fault protection and optional rapid shutdown (depending on Synergy Manager used) Built-in PID mitigation for maximized system performance. Monitored and field-replaceable surge protection devices: integrated RS485 and Type 2 DC SPDs, optional Type 2 AC SPD. Integrated DC safety switch eliminates the need for external DC isolators. DC Fuses (Single Pole) 25A, optional required for more than 3 strings only  25Amp fuse is NOT compatible with the S1200 optimisers. 30Amp fuse (per phase) replacement is required for this inverter to work with the S1200 optimiser.    Please note FULL parts consist of 1x Synergy Manager and 2x Synergy Units ( 3x for 90 and 100kW) Weight: 82 kg Rated Power: 66,600 W Min PPT Voltage: 0 V Max PPT Voltage: 0 V DC Startup Voltage: 0 V DC Shutdown Voltage: 0 V Max Input Voltage: 1,000 V Max DC Power: 74,250 W Max AC Power (5 Minutes): 55,000 W Surge AC Power (1 Second): 55,000 W Max DC Current: 80 A Max DC Inputs: 6 Has DC Fuses: 12 Connector: MC4   Included Connectors: 12 Euro Efficiency: 98 % Transformer: None MPPT Quantity : 0 Has Integrated DC Switch: Yes Warranty: 12 years

Read more less
