The iCS Home Battery Storage system is flexible, modular, has great safety credentials and can be fully integrated with Solar PV systems & even EV Charge points, all controllable from one APP. The system can also utilise off peak electricity tariffs by charging batteries when energy costs are at their lowest and be deployed during peak times. The high-performance inverter and battery modules allow for fast charging and a continuously rated 21.7A output for less reliance on the grid when multiple appliances and loads being used together. The system also provides an emergency output in case of grid power cuts, again continuously rated at 21.7A output.
Features
- Indoor or outdoor installation [IP65]
- Full integration with iCS EV chargers
- Full app control and monitoring
- Twin solar inputs [2 x MPPT's]
- Charge from solar or off peak grid
- High performance [5kW]
- Emergency output or power in emergency [blackout]
- The high performance inverter and battery modules allow for fast charging and a continuously rated 21.7A output for less reliance on the grid when multiple appliances and loads being used together
- Can be fully integrated with solar PV systems
Supplier Part No:ICSESSH5KWeight:32 kgRated Power:5,000 WMin PPT Voltage:125 VMax PPT Voltage:500 VDC Startup Voltage:125 VDC Shutdown Voltage:125 VMax Input Voltage:550 VMax DC Power:7,000 WMax AC Power (5 Minutes):5,000 WSurge AC Power (1 Second):5,001 WMax DC Current:28 AMax DC Inputs:2Has DC Fuses:0Connector:MC4 Included Connectors:1Euro Efficiency:97.6 %Transformer:NoneMPPT Quantity :2Has Integrated DC Switch:No
