Sunsynk

9 UNITS IN STOCK Part No: SUN-BAT-CATL-5.12 Storage Systems - Li-ion Battery Pack Brackets not included; You can use either of the following: SUN-WALL-BR; Battery Wall mount bracket for 1 battery Introducing Sunsynk's energy storage module well designed for residential UPS and off-grid applications. Cells produced by CATL, a global leader in lithium-ion battery developement and manufacturing. Product Features Long life span with an expected life of 10-years 5-year product warranty(non extendable) 10-year performance warranty Parallel capability of 16 units 100% Depth of Discharge 5.12kW maximum discharge power (C0.5 rated)  Batteries provide excellent thermal stability and storage and also has a self-monitoring function to detect abnormalities.  IP rating 40   INSTALLER NOTICE: Installations with Sunsynk products now need to be registered here.  Supplier Part No: Sunsynk CATL Battery LFP 5.12kWh Weight: 47.5 kg Battery Type: Lithium Ion Nominal Energy: 5120 Wh Depth of discharge: 100.00 % Voltage: 48 V Continuous Discharge Rate (Normal Use): 2400 W Maximum Discharge Rate (5 Minutes): 4800 W Surge Discharge Rate (15 Seconds): 9600 W Maximum Charge Rate (5 Minutes): 4800 W Data Sheet Sunsynk CATL Battery 5.12

Read more less

4 UNITS IN STOCK  Part No: SUN-3.6-ECCO Storage Systems - Hybrid Inverter The SunSynk 3.6kW AC ECCO 7kWp Inverter is the next generation of super hybrid inverter with a 7000W MPPT and a rated AC output of 3.68 resulting in a system that can generate sufficient energy in Winter months to offset usage and charge a connected battery. The inverter boasts additional features such as; Dual MPPT design  Compatible with Lithium-ion batteries and Lead Acid batteries Up to 50kWh battery pack 5yr warranty as standard IP65 rated Anti-islanding protection Fully programmable power export Automatic switching from Grid-Tied to Off-Grid mode Up to 16 units with the same firmware can be paralleled  Supplier Part No: SUNsynk-3.5K-SGO1LP1 ECCO Weight: 20.5 kg Rated Power: 3,600 W Min PPT Voltage: 125 V Max PPT Voltage: 500 V DC Startup Voltage: 150 V DC Shutdown Voltage: 125 V Max Input Voltage: 500 V Max DC Power: 7,000 W Max AC Power (5 Minutes): 3,960 W Surge AC Power (1 Second): 5,400 W Max DC Current: 22 A Max DC Inputs: 2 Has DC Fuses: 0 Connector: MC4   Included Connectors: 0 Euro Efficiency: 99.9 % Transformer: None MPPT Quantity : 2 Has Integrated DC Switch: Yes Data Sheet 3.6 ECCO

Read more less

Part No: SUN-5.0-ECCO Storage Systems - Hybrid Inverter The Sunsynk 5kW ECCO hybrid Inverter is the ideal inverter for managing power flow from multiple sources such as solar, main electrical grid and generator. All of the power of the previous Sunsynk model in a smaller package! Product Features Dual MPPT design  Compatible with most Lithium-ion batteries and Lead Acid batteries Mobile App for monitoring IP65 rated Automatic switching from Grid-Tied to Off-Grid mode Zero export function Up to 16 units with the same firmware can be paralleled Essential and Non-Essential Loads outputs Comes with the Wi-Fi logger and CT Compatible with SolarMan App for Monitoring  Supplier Part No: Sunsynk-5.5-K-SG01LP1 ECCO Weight: 25 kg Rated Power: 5,000 W Min PPT Voltage: 125 V Max PPT Voltage: 425 V DC Startup Voltage: 150 V DC Shutdown Voltage: 150 V Max Input Voltage: 500 V Max DC Power: 6,500 W Max AC Power (5 Minutes): 5,500 W Surge AC Power (1 Second): 11,000 W Max DC Current: 22 A Max DC Inputs: 2 Has DC Fuses: 0 Connector: MC4   Included Connectors: 0 Euro Efficiency: 96.5 % Transformer: None MPPT Quantity : 2 Has Integrated DC Switch: Yes Data Sheet 5.0 ECCO (draft)

Read more less

Part No: SUN-16.0 Storage Systems - Hybrid Inverter The 16kW single-phase hybrid inverter is the biggest addition to Sunsynk’s low voltage (48V) single-phase inverter range. It’s suitable for off-grid, grid support, backup, and self-consumption PV systems and can also be used in both three-phase and single-phase parallel applications.  In terms of functionality, compatibility, and related accessories, it’s similar to the 5kW & 8kW units but particularly suited to large domestic and small commercial installations.   “It’s the biggest single phase all-in-one inverter with everything built in, in the world”, Keith Gough, Sunsynk CEO. A true monster!  Additional features:  A total of 15x inverters can be connected in a three-phase configuration (five units per phase) - giving a maximum power output of 240kW  Three inverters can be connected in a single-phase configuration giving a total power of 48kW  Contains 3x MPPTs to allow for flexible PV array designs and improved efficiency  Programmable multiple operation modes: on-grid/off-grid & UPS  IP65 protection rating  Wi-Fi dongle as standard – enabling remote monitoring via the Sunsynk cloud  Compatible with leading lithium battery brands such as Hubble Lithium, Pylontech LV, Freedomwon and Kodak (BL3.6)  Sunsynk inverter and Freedom Won battery pairing : 10-year extended warranty. For installations with Pylontech, REVOV and Hubble Lithium batteries use this BMS cable For installations with Freedom Won batteries use this BMS cable Installations with Sunsynk products need to be registered to gain full activation of the warranty. Register here>> Equipment warranty registration needs to take place within 7 (seven) days of commissioning of the project, failure to register the warranty may result in the warranty being made void.   Supplier Part No: SUNSYNK-16K-SG01LP1 Weight: 56 kg Rated Power: 16,000 W Min PPT Voltage: 250 V Max PPT Voltage: 450 V DC Startup Voltage: 150 V DC Shutdown Voltage: 0 V Max Input Voltage: 450 V Max DC Power: 18,000 W Max AC Power (5 Minutes): 16,001 W Surge AC Power (1 Second): 32,000 W Max DC Current: 66 A Max DC Inputs: 6 Has DC Fuses: 0 Connector: Screw Terminal   Included Connectors: 12 Euro Efficiency: 97.6 % Transformer: None MPPT Quantity : 3 Has Integrated DC Switch: Yes Warranty: 5 years Data Sheet For Sunsynk 16kW

Read more less

Part No: SUN-3.6-SUN-5.12 Storage Systems - Grid Backup Packages This part is a special offer made up of the following items: Part   1 x Sunsynk CATL Battery LFP 5.12kWh   1 x  Sunsynk 3.6kW AC 7kWp ECCO Hybrid Inverter   1 x  Battery Wall Mount Bracket Sunsynk   1 x  Battery to Inverter Cable Pack Long for Sunsynk CATL only   1 x  Jean Muller Fuse-switch-disconnector KETO size 00 body (battery isolator)   2 x  NH Fuse-link 125A for KETO-00   The Sunsynk hybrid Inverter is modern inverter for managing power flow from multiple sources such as solar, main electrical grid and generator. This Sunsynk inverter comes paired along with a Sunsynk CATL 5.12kWh battery package, a complete storage solution providing grid-backup for loads.   Weight: 75.57 kg Rated Power: 3,600 W Data Sheet Sunsynk CATL Battery 5.12

Read more less

7 UNITS IN STOCK Part No: SUN-BAT-BYD-5.12 Storage Systems - Li-ion Battery Pack Introducing Sunsynk's energy storage module well designed for residential UPS and off-grid applications. Cells produced by BYD. This Battery is the wall mounted version. Product Features Long life span with an expected life of 10-years 5-year product warranty(non extendable) 10-year performance warranty Parallel capability of 16 units 100% Depth of Discharge 5.12kW maximum discharge power (C0.5 rated)  Batteries provide excellent thermal stability and storage and also has a self-monitoring function to detect abnormalities.  IP rating 40 INSTALLER NOTICE: Installations with Sunsynk products now need to be registered here.  INSTALLER NOTICE: It is advised to connect these batteries side to side since the battery cables are not long enough to connect batteries above or below.   WARNING: These batteries contain BYD cells, not to be mistaken for the SUNSYNK CATL 5.12KW which contain CATL cells.  Supplier Part No: SUN-BAT-BYD-5.12 Weight: 48 kg Rated Power: 5,120 W Battery Type: Lithium Ion Nominal Energy: 5120 Wh Depth of discharge: 100.00 % Voltage: 48 V Continuous Discharge Rate (Normal Use): 2400 W Maximum Discharge Rate (5 Minutes): 4800 W Surge Discharge Rate (15 Seconds): 9600 W Maximum Charge Rate (5 Minutes): 4800 W

Read more less

Part No: SUN-8.0-ECCO Storage Systems - Hybrid Inverter The Sunsynk 5kW hybrid Inverter is the ideal inverter for managing power flow from multiple sources such as solar, main electrical grid and generator.  Product Features Dual MPPT design  Compatible with most Lithium-ion batteries and Lead Acid batteries Mobile App for monitoring IP65 rated Automatic switching from Grid-Tied to Off-Grid mode Zero export function Up to 16 units with the same firmware can be paralleled Essential and Non-Essential Loads outputs Comes with the Wi-Fi logger and CT Compatible with SolarMan App for Monitoring Pylontech Compatibility Tested: US 3000C  US 2000B-Plus US 3000B Not currently tested with Pylon – LV Hub please consult with us before proceeding   For installations with the US3000C and UP5000 please use the following BMS cable SUN-CAN-3M   INSTALLER NOTICE: Installations with Sunsynk products now need to be registered here to gain full activation of the warranty. BEFORE INSTALLATION, please ensure that you check that the Inverter is updated to the latest firmware version.  Latest Version 3367 E41C Supplier Part No: Sunsynk-8.8-K-SG01LP1 ECCO Weight: 25 kg Rated Power: 8,000 W Min PPT Voltage: 125 V Max PPT Voltage: 425 V DC Startup Voltage: 150 V DC Shutdown Voltage: 150 V Max Input Voltage: 500 V Max DC Power: 6,500 W Max AC Power (5 Minutes): 8,001 W Surge AC Power (1 Second): 8,002 W Max DC Current: 22 A Max DC Inputs: 2 Has DC Fuses: 0 Connector: MC4   Included Connectors: 0 Euro Efficiency: 96.5 % Transformer: None MPPT Quantity : 2 Has Integrated DC Switch: Yes   Data Sheet 8.0 ECCO (draft)

Read more less
